MT battery contains gel electrolyte primarily produced by the homogeneous distributed SiO in a diluted sulfuric acid named gel 2SOL with thixotropic properties. The special designed vent valves are also used to control the gassing and water losing rate.
- Adopting gel battery technology for long time backup power
- Excellent deep cycle performance
- Gas recombination efficiency (>99%)
- Advanced phenolic resin separator
- Mechanical capacity to resist high temperature
Model | Voltage | Capacity | Dimension(mm) | Terminal | |||
(V) | (Ah) | Length | Width | Height | Total Height | ||
MTG10-12 | 12 | 10 | 151 | 98 | 95 | 101 | F1/F2 |
MTG12-12 | 12 | 12 | 151 | 98 | 95 | 101 | F1/F2 |
MTG17-12 | 12 | 17 | 181 | 77 | 167 | 167 | F13 |
MTG20-12 | 12 | 20 | 181 | 77 | 167 | 167 | F13 |
MTG24-12 | 12 | 24 | 175 | 166 | 125 | 125 | F13 |
MTG33-12 | 12 | 33 | 195 | 130 | 155 | 168 | F11 |
MTG40-12 | 12 | 40 | 197 | 165 | 170 | 170 | F11 |
MTG45-12 | 12 | 45 | 197 | 165 | 170 | 170 | F11 |
MTG55-12 | 12 | 55 | 229 | 138 | 208 | 213 | F11 |
MTG65-12 | 12 | 65 | 350 | 167 | 179 | 179 | F11 |
MTG75-12 | 12 | 75 | 258 | 166 | 210 | 215 | F21 |
MTG80-12 | 12 | 80 | 350 | 167 | 179 | 179 | F11 |
MTG90-12 | 12 | 90 | 306 | 169 | 210 | 215 | F21 |
MTG100-12 | 12 | 100 | 330 | 171 | 215 | 220 | F12 |
MTG120-12 | 12 | 120 | 410 | 176 | 227 | 227 | F12 |
MTG134-12 | 12 | 134 | 341 | 173 | 283 | 287 | F12 |
MTG150-12 | 12 | 150 | 482 | 170 | 240 | 240 | F12 |
MTG175-12 | 12 | 175 | 530 | 209 | 215 | 220 | F12 |
MTG180-12 | 12 | 180 | 522 | 238 | 218 | 223 | F12 |
MTG200-12 | 12 | 200 | 522 | 238 | 218 | 223 | F12 |
MTG250-12 | 12 | 250 | 520 | 269 | 221 | 227 | F12 |
