- Prismatic LiFePO4 cells, Longer cycle life and much more safety
- Low voltage system, safety for application
- IEC62619, UL1642, UN38.3 certification for cell
- UN38.3 certification for system
- Standard 19" rack design
- Flexible and easily installation
- -20~+55°C widely temperature range
- Maintenance free
- Independent protection for charge and discharge
- SOC, SOH display and PC software for detailed operation
- OVP, LVP, OCP, OTP, LTP protection
- RS232, RS485,CAN communication port
Model | Nominal voltage | Typical capacity | Charge current | Constant discharge current/ | Weight | Dimension（mm) | Remark | Cycle life | Warranty | Communication |
(V) | (Ah) | (A) | Peak current (3S) | (Kg) | ||||||
LFP4810 | 48 | 11 | 5 | 10A/20A | 7 | 442*330*44 | Support 16P | 6000 | 5Y | RS485/CAN |
LFP4820 | 48 | 22 | 10 | 20A/40A | 13 | 442*330* 88 | Support 16P | 6000 | 5Y | RS485/CAN |
LFP4850 | 48 | 50 | 25 | 50A/100A | 24 | 442*390*88 | Support 16P | 6000 | 5Y | RS485/CAN |
LFP48100 | 48 | 100 | 50 | 100A/120A | 45 | 442*480*155 | Support 16P | 6000 | 5Y | RS485/CAN |
LFP48150 | 48 | 150 | 50 | 100A/120A | 65 | 442*465*178 | Support 16P | 6000 | 5Y | RS485/CAN |
LFP48180 | 48 | 180 | 50 | 100A/120A | 72 | 442*550*226 | Support 16P | 6000 | 5Y | RS485/CAN |
LFP48200 | 48 | 200 | 50 | 100A/120A | 76 | 442*580*226 | Support 16P | 6000 | 5Y | RS485/CAN |
LFP48240 | 48 | 240 | 50 | 100A/120A | 95 | 442*600*264 | Support 16P | 6000 | 5Y | RS485/CAN |
