LFP 24V-MT-battery

LFP 24V

Product Introduction

25.6V Lithium Iron Phosphate Battery

Product Features

- Prismatic LiFePO4 cells, high consistency, long cycle life and much more safety

- UN38.3, CE certification for system

- The cycle life over 3000 times @80%DOD

- ABS container, replace VRLA battery perfectly

- Fast charge performance

- -20~+55° C widely temperature range

- Maintenance free

- Integrated hardware BMS inside

- Independent protection for charge and discharge

- Over voltage, low voltage, over temperature and short circuit protection

Product Parameters

LiFePO4	Nominal	Nominal	Nominal	Max Charging current	Max Discharge current	Impluse/3S	Dimensions（LWH)			Approx.	Terminal	IP Class	In series	Blue tooth	LCD
	Voltage	Capacity	Energy	Max Charging current	Max Discharge current	Impluse/3S	Dimensions（LWH)			Weight	Terminal
	[V]	[Ah]	[Wh]	[A]	[A]	[A]	L [mm]	W [mm]	TH [mm]	[kg]	Type
LFP50-24	25.6	50	1280	25	50	150	330	172	215	13.2	Insert M8	IP50	2S	P	P
LFP60-24	25.6	60	1536	30	60	180	260	180	257	17.5	Insert M8	IP50	2S	P	P
LFP85-24	25.6	85	2176	43	85	255	483	170	240	20.6	Insert M8	IP50	2S	P	P
LFP100-24	25.6	100	2560	50	100	300	483	170	240	22	Insert M8	IP50	2S	P	P
LFP120-24	25.6	120	3072	50	100	300	483	170	240	26.5	Insert M8	IP50	2S	P	P
LFP150-24	25.6	150	3840	50	100	300	520	269	208	35	Insert M8	IP50	2S	P	P
LFP200-24	25.6	200	5120	50	100	300	520	269	208	43	Insert M8	IP50	2S	P	P
LFP100-48	51.2	100	5120	50	100	600	520	269	208	40	M8	IP50	N	P	P
